Features

• Dual isolated channels
• LCD display
• Digital control panel design, easy-to-operate
• 21 modes available for selection
• Doctor "lock" feature
• Belt clip
• Auto shut-off function
• Treatment timer preset

• Comes with 1 pkg of 4 reusable self-adhering electrodes, 1 set 43” pin lead wires, 2 each AA 1.5V heavy duty batteries, carrying case, and instruction manual

• Leadwire reorder # LW46SPLE


Technical Specifications

• Channel: Dual, isolated between channels
• Amplitude: 0 - 100mA (500 ohm load)
• Output Voltage: 0 - 40 V (500 ohm load)
• Waveform: Symmetrical biphasic rectangular, symmetrical alternated rectangular
• Pulse Rate:1 - 150 Hz
• Pulse Width: 50 - 400 µS, 50 µS per step
• Contraction Time: 1 - 60 seconds
• Relaxation Time: 0 - 60 seconds
• Ramp Up/Down: 0 - 5 seconds, in steps of .25 seconds
• Timer: 10, 20, 30, 45, 60 minutes or continuous
• Modes: 4 manual modes, 17 preset modes
• Compliance Timer
• Power Supply: 2 alkaline AA 1.5V batteries
• Size: 13.6 x 6.6 x 3.1 cm
• Weight: 148 grams including battery
