Nu-Wave TENS Unit

Features

• Dual channel (4-lead) all digital TENS

• One preprogrammed treatment mode

• Stronger symmetrical biphasic waveform for deeper penetration with clinically proven results

• Microprocessor controlled technology

• Fixed pulse rate and pulse width
• Fixed treatment program time

• Removable plastic belt clip

• 3-year warranty

• Comes with 1 pkg of 4 reusable self-adhering electrodes, 1 set 36” pin lead wires, 2 each 9V alkaline batteries, zippered carrying case, and instruction manual

• Leadwire reorder #LW620060-36


Technical Specifications

Channel Dual
Amplitude 100 mA peak into 500 ohms constant at 60 µS width and maximum intensity
Output Voltage 100 V
Waveform Proprietary symmetrical biphasic waveform with tuned intrapulse interval and width
Pulse Rate 278 Hz
Pulse Width 60 µS
Power Supply 9-volt battery
Size 10.7 x 5.3 x 2.3 cm
Weight 119 grams with battery
